Wiring Diagram
Mains
Power supply unit
230V
2
24VDC
FAS
Unlocking via fire
alarm system
2
2
Door contact
(omitted with model 331)
Door locking with
Holding magnet model 828 (2x)
Electric panic opener 3150
Escape door lock release 331
max.5
Door terminal with integrated
escape door
control 1340-10 (24 V)
(Acoustic alarm)
(Display LED
rd/gn/ye)
(Key- operated
switch lock/un-
lock to ex-
tinguish alarm)
O
(EMERGENCY OPEN
switch lights up)
U
7
Central indicator panel 725 (if required)
829,
827 (2x),
17
