User Manual
Dual video
There are two dual video configurations, each displaying two inputs side by side. To access dual video
mode press quadview and then the mode button six times, alternatively you may access dual video
mode by pressing the mode button until you reach the first dual mode configuration. The first
configuration shows inputs 1 and 2 side by side, press the mode button again and the second
configuration shows inputs 3 and 4 as shown below.
When dual video mode is being used the audio channel in use will be from the most recently used
channel, so for example if you switch from input 3 directly to quadview mode and then to dual video
mode the audio from input 3 will be used. Audio switching can be completed using the instructions from
picture and picture mode.
Troubleshooting
There is no audio
•
Please check the active audio channel by pressing the audio button on the switch or remote control
until the ♪ icon is present in the correct channel.
Picture is distorted, incomplete, missing colours etc.
•
Please check that all HDMI cables are correctly seated in the ports and reboot the connected source
devices.
• Check that video scaling is correctly configured on any connected PC's graphics card:
AMD
1. Open the AMD Control Centre. In the My Digital Flat Panels menu select Properties (Digital Flat-
Panel).
2. Tick the Enable GPU scaling box under Image Scaling and then select Scale image to full panel size.
3. Now select Scaling Options from the My Digital Flat Panels menu and set the Scaling Options to 0%.
NVIDIA
1. Open the NVIDIA Control Panel. In the Display menu select Adjust desktop size and position.
2. In the Scaling tab select Full Screen from the scaling mode list and then GPU from the Perform
scaling on drop down box.
