User Manual
Introduction
Thank you for purchasing the LINDY HDMI 4x1 Multi-View Switch. This product has been designed to
provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
The LINDY HDMI 4x1 Multi-View Switch is a high performance video switch which allows signals from
four different Full HD sources to be integrated for simultaneous display on a single monitor. It can
seamlessly switch between each of the connected inputs and features three different viewing modes and
supports the independent switching of audio signals. This flexible, cost effective switch has been
designed to be used in a number of different applications, such as:
▪
Digital Presentation
▪
CCTV Surveillance & Control
▪
Conference & Meeting Room
Package Contents
▪
HDMI 4x1 Multi-view Switch
▪
IR Remote control with 2 x AAA batteries
▪
Multi-Country Power Supply 12VDC 2A (UK, Euro, US & AUS)
▪
LINDY User Manual
Features
▪
Integrates 4 Full HD 1080p signals for display on a single HDMI display
▪
Supports 4 viewing modes; Quadview, Picture & Picture, Dual Video and Standard
▪
Seamless switching between inputs/viewing modes
▪
Independent switching of audio and video signals
Specification
▪
Supports 4 viewing modes:
▪
Standard
▪
Quadview/Multi-Window Display
▪
Picture and Picture
▪
Dual video
▪
HDMI 1.3a, HDCP 1.2 and DVI 1.0 Compliant
▪
Supports input resolutions up to 1920x1080p 60Hz 4:4:4 8bit
▪
Output resolution: 1920x1080p 60Hz 4:4:4 8bit or 1280x720p 60Hz 4:4:4 8bit
▪
Supports cable lengths of up to 15m in/out using 26 AWG cable
▪
Independent switching of audio
▪
Connectors:
▪
Inputs: 4 x HDMI Type A Female
▪
Output: 1 x HDMI Type A Female
▪
Seamless switching between inputs/viewing modes
▪
Audio Pass-through: 2 channel PCM
▪
Supports IR remote control and on-panel control
▪
Power Consumption: 6W
▪
Operating Temperature: 0
▪
Storage Temperature: -20
▪
Operating Humidity: 20%-90% RH (non-condensing)
▪
Storage Humidity: 40%-60% RH
C – 40
0 0
C
C – 60
0 0
C
English
