Preparing the vacuum cleaner for
operation
1 Insert the curved hose end in the opening of the vacuum
cleaner and gently press. A characteristic click indicates that
the hose has been properly installed.
2 Connect the other end of the hose (handle) with the
telescopic suction tube. In order to do so press the locking
device "A" and slide the tube into the hose handle so that
the locking device "A" is blocked in opening "B".
3 Adjust the length of the telescopic suction tube by sliding
the slider according to the arrow and pull out/pull the tube
together.
4 Assemble the appropriate nozzle or brush to the other
end of the suction tube.
5 You may assemble a basket for picking up small objects
in the combination brush with the small item separator. In
order to do so remove the blank cover and insert the basket.
6 Use combination carpet & floor brush for vacuuming both
hard surfaces and carpets. To clean hard surfaces – wooden
floors, plastic floors, ceramic tiles etc. pull out the brush by
pressing the switch on the combination brush according to
the figure . Retract the brush when vacuuming carpets
(set the switch in " ").
7 Grab the plug (6) and pull the cord out of the vacuum
cleaner.
8 Plug in the appliance.
Before operation make sure that the SAFBAG bag is
installed in the vacuum cleaner chamber and that inlet filter
and the HEPA H11 outlet filter is installed in the appliance.
9 Switch on the vacuum cleaner by pressing the "on/off"
button (1).
10 The vacuum cleaner is equipped with an electronic
power control which allows to gradually adjust the
vacuum cleaner suction power during operation. To adjust
the suction power use the power adjustment buttons (9, 11)
– to increase the suction power or
suction power. The suction power setting is indicated by the
appropriate number of lit diodes.
The vacuum cleaner is equipped with a power
level memory function. When you turn off the
vacuum cleaner using the ON/OFF button
(1), the power level is going to be stored in
memory. After the vacuum cleaner is turned
on next time, it is going to start working at the
same power level it had been working before it
was turned off.
The suction power may be adjusted during operation.
The recommended settings are:
Setting 1 – vacuuming curtains
Setting 2 – vacuuming upholstery
Setting 3 – cost-effective power
Setting 4 – vacuuming carpets
Setting 5 – vacuuming hard floors and crevices.
16
The power may also be adjusted individually depending on
B
the type of surface, vacuum effectiveness and suction power
of the switchable combination brush.
11 The vacuum cleaner is equipped with an accessory
compartment. To open the compartment lift the vacuum
cleaner handle and pull the accessory compartment cover
(5) upwards.
12 The accessories may be attached to the accessory
holder in the suction hose handle. This way they will be
available for use at any time.
13 The vacuum cleaner is equipped with the "Parksystem"
function. This function allows to temporarily switch off the
vacuum cleaner using the fastening hook of the combination
brush without the necessity to use the on/off button. In order
to do so, during operation insert the fastening hook of the
combination brush in the combination brush fastening (5).
The vacuum cleaner will automatically switch off.
Filter disassembly
– to decrease the
Before changing the filters make sure that the vacuum cleaner
is switched off and unplugged from the mains supply.
INLET FILTER
1 Release the front cover fastening (13) and open the cover.
2 Slide the inlet filter (16) from the appliance body.
3 Insert the new filter making sure that the outer edge of
the filter is located to the inside of the limiting rib.
4 Close the front cover.
HEPA H11 OUTLET FILTER
The vacuum cleaners are equipped with an outlet filter
HEPA H11.
1 The HEPA outlet air filter needs to be replaced when the
surface of the filter is dirty or the control lamp of the outlet
filter replacement indicator lights up (8) (pulsing red light).
The suction power of the vacuum cleaner will reduce to
setting 1 when the outlet filter replacement indicator lamp
lights up.
The vacuum cleaner is equipped with the
adjustment function for LED brightness of the
power level indicator (10) on the control panel.
In order to set a demanded LED brightness,
you have to press both of the power adjustment
buttons (9) and
pressing these buttons turn on the vacuum
cleaner by pressing the ON/OFF button (1). The
LED for power levels 1, 3, and 5 turn on, and
the motor stays turned off. Next by pressing
the power adjustment buttons
(11) you can respectively increase or decrease
the brightness of power level indicator (10).
After setting a desired LED brightness, it is
necessary to turn off the vacuum cleaner using
the ON/OFF button (1). In this way you leave
the LED brightness adjustment function mode,
and the set LED brightness level is stored.
(11), and when still
(9) and
C
D
