CAUTION
– Do not use bent, deformed or damaged bur. If these burs are used, they could bend or suddenly break during
rotation. Bur may become di cult to remove because latch groove is worn or it has swollen.
– Always keep bur shanks clean. Dirt or debris in a chuck could cause poor bur concentricity or low chuck retention force.
– Do not exceed the drive motor speed recommended by the bur manufacturers.
– Do not apply excess pressure to the bur as it may break or bend or become di cult to remove.
– Before use always confi rm that the bur is correctly seated and locked into place.
– Always use with adequate water supply and coolant air or damage to the tooth structure and overheating may occur.
– If a foreign material enters the gears or internal mechanism of the handpiece, it may result in burn injuries.
– Use eye protectors, dust mask, for safety and health during treatment.
– Perform periodical maintenance checks.
– If the handpiece has not used for a long period, check for noise, vibration,and overheating before use.
– Do not wipe nor immerse the handpiece acidic water or acidic solutions.
– User is responsible for operation, maintenance and safety.
– Do not use the handpiece if the bur is not correctly mounted, otherwise the chuck might be thrown by the
reactive force and the bearing might be damaged.
16
1. Specifi cation
Model
Max.Rotation Speed
Max.Rotation Speed
Bur
Optic
Bur applied Length
Max Bur Length
Max Bur diameter
Water Spray Type
Use Environment
Temperature: 10-40°C (No Condensation), Humidity: 30-75%
Transportation and Store Environment
RED L-200
200 000 t/min
1:5
ISO1797-1 Type 3 Ø 1,60 mm Fraise FG
Glass Rod
10,9 mm
25 mm
Ø 1,60 mm
Quadruple Spray
Temperature: -10-50°C Humidity: 10-85%,
Atmospheric Pressure: 500-1,060hPa
