3TECH RED L-200 Mode D'emploi page 12

CAUTION
Do not use a pointed tool or sharp edged to clean the Cellular Glass Optic Rod. They may damage the mirror fi nish
and reduce the light transmission e ciency.
5.3 Disinfection
Wipe the external surface of handpiece carefully with cleaning or disinfectant solution.
5.4 Lubrication
To prevent mist spray from escaping into the environment, use absorbent cloth to absorb excess lubrication.
– Push or screw nozzle. Shake the spray can 3-4 times.
– Insert the spray nozzle in the rear of the handpiece and spray for approximately 2-3 seconds until the oil comes
out of the handpiece head / nose.
22
Automated:
Clean and lubricate handpieces be sure to use a right adaptor for each handpiece.
E spray nozzle
SPRAY
CAUTION
– Be sure to hold the handpiece fi rmly to prevent the handpiece from slipping out from the spray pressure when
lubricating.
– Keep the can upright.
Contra-angle
contra hand
SPRAY
Fig. 5.2
23
