1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your CP series Filter Pump.
2. Before you begin to assemble the pool, identify, count, and check all parts needed for assembly.
3. It is recommended that you have some PETROLEUM JELLY on hand for lubricating the gaskets.
1. Installer shall follow written instructions provided for operation of the filter pump systems.
2. All electrical components shall be installed in accordance with Article 680 of the National Electrical Code (NEC) "Swimming Pools, Fountains and Similar
Installations" or its latest approved edition.
3. DO NOT use this product to dispense powdered chlorine, shock treatment or any other type of chemicals as damage to the pump, filter cartridge, and pool will occur.
4. The CP Series Filter Pump systems are manufactured by BLUE WAVE and ETL control number 4000608 and 4006317 - double insulated and grounded - 120
Volts A.C. - 60 Hz. (ALL Units must have a minimum of 105 Volts A.C. to start and run properly.)
FILTER PUMP POWER INFORMATION
FILTER PUMP MODEL
CP2000-C Filter System Pump
ITEMS
1
2
Suction Fitting Thrust Washer (SF Washer)
3
Fitting Lock Nut
4
Suction Fitting Cap (SF Cap)
5
6
Return Fitting Diverter (RF Diverter)
7
RF Locking Ring
8
9
RF Thrust Washer
PRELIMINARY STEPS
FILTER PUMP IMPORTANT NOTES
PARTS LIST
PARTS NAME
Fitting Gasket
Suction Fitting
Return Fitting
RF 90˚ Elbow
RF Nut
RF Gasket
OWNER'S MANUAL
WATTAGE
360 Watts
QTY.
ITEMS
1
1
1
1
1
1
1
1
1
1
GFCI Power Cord Set (Image Reference Only)
1
1
AMPERAGE
3.0 Amps
PARTS NAME
Hose
Hose Clamp
Filter Pump Assembly
Vent Screw
Vent Screw O-Ring
Seal Top
Canister Gasket
O-Ring (On Hose Connections)
Type A/C Filter Cartridge
Return Fitting Plug (RF Plug)
QTY.
2
4
1
1
1
1
1
4
1
1
1
7
