5. Connect the Hose from the Return Fitting to the Filter Pump
r
Outlet.
Filter Pump Outlet
7. Tighten all Hose Clamps
t
9. Vent the Pump: to release the air trapped inside and make sure a smooth
water flow, it's important to vent or depressurize the Pump before each use.
Simply twist counterclockwise to loosen the Vent Screw
pressure will force all the trapped air out. Retighten the Screw when water
starts flowing out from the Seal Top
10
14
13
to prevent water leakage.
, and the water
u
.
o
6. Connect the Hose from the Suction Fitting to the Pump Inlet.
r
POOL POOL
RETURN SUCTION
FITTING FITTING
Filter Pump Inlet
8. Do not plug in the filter pump at this point. Begin to fill water until
the water level reaches the fill line.
10. Hand loosen the RF Locking Ring
Diverter to maximize the circulation of the pool water. Hand
7
tighten the RF Locking Ring
NOTE: It is recommended to point the
diverter down and away from the suction or
water intake for optimum pool circulation.
360°
. Adjust the Return Fitting
8
.
8
8
