Installation Instructions
STEP 9 POSITION DISHWASHER
UNDER COUNTERTOP
against the door since door damage will occur.
into the cabinet.
panel does not catch or rub on the cabinet frame.
and does not contact the cabinet frame.
The controls on these models are designed to be hidden by
countertop and the top of the dishwasher door as shown in
Note: If the drain hose gets trapped behind the unit it can
prevent the controls from being hidden by the countertop.
Note:
dishwasher, the old countertop bracket screw holes may
not be in the correct position to accept a top-control model.
New holes may be required.
Tip: The leveling legs can be used to increase or decrease
the amount of gap between the controls and the countertop
affecting the visibility of the controls.
IMPORTANT – Leave a 1/2" minimum gap between
the controls and the underside of the countertop to
prevent condensation and damage to the control panel
from screwheads.
Figure P
Figure Q
Top View
ON
DELAY
OFF START LOW RINSE AID
1 - 24 HRS.
Controls Hidden
by Countertop
Figure R
Countertop
Control
Panel
Figure S
Countertop
1/2"
Min.
Dishwasher
Door
Figure T
