G2511-115
Repair
Dismantling
Service tools are also included in our basic service tools set. For further information see ordering No.9835 5485 00
Mandrel A
Ordering No.
4080 0182 01
4080 0182 02
4080 0182 03
4080 0182 04
4080 0182 05
4080 0182 06
4080 0182 07
4080 0182 08
4080 0182 09
4080 0182 10
4080 0182 11
4080 0182 12
4080 0182 13
4080 0182 14
4080 0302 00
Inspection of motor parts
Assembling
Service tools are also included in our basic service tools set. For further information see ordering No.9835 5485 00
Mandrel B
Ordering No.
4080 0567 04
EN
C (mm)
3.5
4.5
5.5
6.5
8.5
10.5
12.5
15.5
17.5
20.5
25.5
30.5
35.5
40.5
A
C (mm)
5.2
© Atlas Copco Industrial Technique AB - 9836 9882 00
D (mm)
7
8
9
10
13
16
19
22
24
26
30
35
40
47
A
A
C
D
D (mm)
12.5

Service

11
