PARTS LIST

MODEL NO.: CH7630SQB
CH7636SQB
CH7642SQB
CH7648SQB
Body Components
NO.
1 Screws (3/16 x 3/8 )
2 Hood Casing
3 Hood-Mounting Bracket
4 Screws (3/16 x 3/8 )
5 Stainless Steel Oil Tunnel
6 Blower Assembly
7 Halogen Light Panel
8 Gasket
9
Screws (3/16 x 3/8 )
10 Halogen Light
11 Gasket
12 Stainless Steel Spacer
A
B
C
13 Baffle Filter
14 Baffle Handle
15 Electrical Assembly
16
Screws (3/16 x 3/8 )
17 Wiring Box
18
Screws (3/16 x 3/8 )
19 Switch Assembly
20
Screws (3/16 x 3/8 )
21 Board
22
Screws (3/16 x 3/8 )
DESCRIPTION MODEL/SIZE
CH7636SQB
CH7642SQB
CH7648SQB
23
PART NO.
CH176-1
CH176-2
CH176-3
CH176-1
CH176-4
CH176-5
CH176-6
CH176-7
CH176-1
CH176-9
CH176-8
CH176-11
CH176-12
CH176-18
CH176-13
CH176-14
CH176-15
CH176-1
CH176-16
CH176-1
CH176-17
CH176-1
CH176-18
CH176-1
