DIAGRAMA DE CIRCUITO

MODELO CH7630SQB
NO.: CH7636SQB
BLACK = NEGRO RED = ROJO
BROWN = CAFÉ
PLACA DE PROCESADOR PROCESSOR BOARD
120V 60Hz
MOTOR
CAPACITOR
CONDENSADOR
10uF/450V
10uF/450V
WHITE = BLANCO YELLOW = AMARILLO
TABLERO DE CONTROL CONTROL BOARD
MOTOR
TRANSFORMER
CAPACITOR
CONDENSADOR
10uF/450V
10uF/450V
GREEN = VERDE
99
RED
BLACK
HALOGEN LIGHT
FOCO DE
HALOGENO
