Installation Instructions
RARMN_ _- Mechanical Non-Ducted
Check the contents of the accessories supplied with your air conditioner as shown below:
10
9
2
49-5000406 Rev. 5
6
4
3
1
Number Part Name
1 Filter Cover
2 Filter
3 Knobs
4 Ceiling Panel
5 Side Discharge Ports
6 Direct Discharge Guide
7 Mounting template
8 Junction Box Cover
9 Connection Shield
10 Air division baffle
11 M8 Mounting Bolts
12 Wood screws
13 Sheet metal screws
8
12
7
5
11
QTY.
1
1
2
1
4
1
1
1
1
1
4
8
2
13
5
