ENGLISH
DMX CHART:
CHANNEL 1 = DURATION
DMX VALUE FOGGING TIME
0-15 No fogging
16-31 Constant fogging
32 0.5 sec
35 0.7 sec
40 1.0 sec
45 1.5 sec
50 1.6 sec
55 1.8 sec
60 2.0 sec
65 2.3 sec
70 2.5 sec
75 2.8 sec
80 3.0 sec
85 3.3 sec
90 3.7 sec
95 4.0 sec
100 4.2 sec
105 4.4 sec
110 4.8 sec
115 5.0 sec
120 5.2 sec
125 5.5 sec
130 5.7 sec
135 6.0 sec
140 6.2 sec
145 6.5 sec
150 7.0 sec
155 7.2 sec
160 7.6 sec
165 7.8 sec
170 8.0 sec
175 8.4 sec
180 8.6 sec
185 8.8 sec
190 9.0 sec
195 9.5 sec
200 9.8 sec
205 10.0 sec
210 10.2 sec
215 10.5 sec
220 10.8 sec
225 11.0 sec
230 11.3 sec
235 11.5 sec
240 11.8 sec
245 12.0 sec
250 12.5 sec
255 12.7 sec
JB SYSTEMS
®
OPERATION MANUAL
CHANNEL 2 = INTERVAL
DMX VALUE INTERVAL TIME
0-15 9 sec
16-31 10 sec
32-47 20-23 sec
48-63 33-36 sec
64-79 46-49 sec
80-95 60-63 sec
96-111 75-78 sec
112-127 92-96 sec
128-143 110-114 sec
144-159 130-133 sec
160-175 150-154 sec
176-191 170-176 sec
192-207 193-200 sec
208-223 213-220 sec
224-239 233-248 sec
240-255 268-278 sec
5/38 FX 1700 FOGGER
ENGLISH
MAINTENANCE
 Switch off the unit, unplug the mains cable and wait until the unit has been cooled down.
During inspection the following points should be checked:
 All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded.
 Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation.
 The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
Cleaning the fogger:
To prevent obstructions in the heater, pump and tubes, the fogger should be cleaned on a regular basis:
every 100h of continuous operation is a good reference.
 Switch the fogger off
 Remove the nozzle (metal part where the fog leaves the fogger)
 Remove the fog liquid from the tank
 Fill the tank with about 1liter of a solution containing 80% distilled water and 20% white vinegar.
 Switch the fogger on and wait for about 8minutes (warm up time)
 Put the fogger in continuous operation mode until the tank is empty
 Put the nozzle back in place
 Remove the eventual residues of the cleaning solution and refill the tank with fog liquid.
Remark: cleaning should be done outside; an awful smell is produced by the vinegar solution!
Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!
SPECIFICATIONS
Mains Input: AC 230V, 50Hz
Power consumption: 1600 Watt
DMX Channels: 2 (fog time + interval time)
10A "auto reset" thermal circuit breaker
Fuse:
Output: 21000 cubic ft/min
Warm up time: 8 min
Tank size: 5L
Size: 435 x 280 x 290 mm
Weight: 10 kg
Every information is subject to change without prior notice
You can download the latest version of this user manual on our website: www.beglec.com
