EN
9. Drive wheel
10. Propeller
11. Nozzle insert
12. Frame
13. Top cover
14. Control unit

Preparation

Place the cleaner into the water, while holding onto the hanging ring
(Fig, 4). Once all the air has escaped from the cleaner, (the cleaner
must be completely free of air, otherwise normal operation will be af-
fected), it will sink to the bottom on its own.
Caution: For optimal performance, make sure that there is no more
air in the cleaner (air bubbles stop coming out of the cleaner, and it
stays on the pool floor properly).

Connecting the power source

When the cleaner is completely on the pool floor, take the power ca-
ble, roll it out fully and push the plug into the socket on the electricity
control box. Then connect the cable to the socket (Please note when
connecting cables that the plugs are in the right direction and posi-
tion in relation to each other), and tighten the nuts on both sides.
Connect the mains cable to the power source. The swimming pool
cleaner is now ready for use.
Panel
NO. SIGN INDICATE
1 ON/OFF Switch on or
Mode options
Fig. 5
Fig. 6
2 MODE
Fig. 7
Fig. 8
Working
Different working duration for dif-
3 TIME duration
option
Page 8 of 60
FUNCTION
- Press this button machine
will be switched on.
- Press this button twice ma-
chine will work under se-
lected mode.
-Press this button third time
machine will be switched
off.
Choose different mode
for different purpose.
"ALL"mode is let machine
clean swimming pool floor
wall and water line together.
(once wall then once floor)
"WALL" mode is let ma-
chine clean swimming pool
wall only.
"FLOOR" mode is let ma-
chine clean swimming pool
floor only.
"ALL + FLOOR" mode is let
machine clean the swim-
ming pool floor three times
then climb wall once.
ferent purpose
1H
Fig. 9
indicate different working duration
Indicate the machine status
Two or three indicators
on
1H flash slowly
2H flash slowly
3H flash slowly
ALL light on
WALL light on
Indica-
4
tor Working
status
FLOOR light on
ALL+ FLOOR light on
ALL>>WALL>>FLOOR
flash in order
FLOOR>>WALL>>ALL
flash in order
3H>>2H>>1H flash in
order
1H>>2H>>3H flash in
order
All lights flash slowly
You can also control the Speedcleaner APPcontrol using the APP.
Please use the following link (Android + IOS): Fig 13.
Bluetooth for smart phone
NO. indicator
1 Bluetooth status
2 Searching signal
▲
3
▼
4
◀
5
Speedcleaner APPcontrol | 2017_V1
2H 3H
Machine
stopped
Machine
running
for 1 hour
Machine
running
for 2 hour
Machine
running
for 3 hour
Working
under
mode ALL
Working
under
mode
WALL
Working
under
mode
FLOOR
Working
under
mode
ALL-
FLOOR
Manual:
forward
Manual:
backward
Manual:
left turn
Manual:
right turn
Auto run
finish
(optional）(Fig. 10)
function
● disconnected
● connected
press to start searching Bluetooth
signal
Manual walking forward
Manual walking backward
Manual left turn
