Appendix A - Falltech DuraTech 6 Mini Single Manuel De L'utilisateur

Model #
Twin Leg SRDs
C72706TB1
C72706TB3
C72706TB4
C72706TB5
C72706TB6
Single Leg SRDs
C72706SA1
C72706SA4
C72706SB1
C72706SB2
C72706SB3
C72706SB4
C72706SB5
C72706SG5
C72706SG6
CMSRD07 Rev A

APPENDIX A

Table 1A: Specifications for DuraTech 6' Web SRD
Lifeline Material Working Length
Dyneema 1.8 m (6 ft)
19mm width
040220
Materials and Capacity and
Specifications Standards
Webbing:
Dyneema
19mm Width
27.1 kN (6100 lbs) Min
Single User
Anchorage Carabiner: Capacity:
22.2 kN (5,000 lbs) Min 54 kg -159 kg
16 kN (3,600 lbs) Gate (120 lbs to 350 lbs)
Strength (combined weight of
user, tools, clothing,
Leg-End Connector: etc.)
22.2 kN (5,000 lbs) Min CSA
16 kN (3,600 lbs) Gate Z259.2.2-17
Strength
SRL-FBH Connector:
Forged Aluminum 13.3 kN
(3,000 lbs) Min
18
