K TECHNICAL DATA
Model / type
Power Input
Power output
Maximum force
Speed
Lighting
Lighting time
Coding
Storm supply transmitter
Frequency
Operating temperature
Max. Door size
Protection class
L PARTS LIST
Part
Garage door drive
Rail
Hand-held transmitter
Door bracket
Wall bracket
Ceiling mount
Release with handle
Door arm
Mounting material
M6 nut
M8 nut
M6 x 14 Hex screw
M8 x 14 Hex screw
M8 x 25 axle pin
M8 x 90 axle pin
M1.8 x 38 split pin
U-mounting bracket
Smart DRIVE 10 PREMIUM /
60912 (DE), 60916 (INT)
220 – 240 V AC 50/60 Hz
200 W
600 N
0.15 m/sec.
LED, 24 V DC
3 min.
Hopping code
23 A 12 V battery
433,92 MHz
-20° to +40° C
10 m
2
only for dry rooms
Amount
1
1
1
1
1
2
1
1
1
2
4
2
4
1
1
2
2
36
Smart DRIVE 14 PREMIUM /
60915 (DE), 60914 (INT)
220 – 240 V AC 50/60 Hz
245 W
1.000 N
0.15 m/sec.
LED, 24 V DC
3 min.
Hopping code
23 A 12 V battery
433,92 MHz
-20° to +40° C
14 m
2
only for dry rooms
