Man & Machine Its Cool Wireless Mode D'emploi

• Operating Manual • Bedienungsanleitung • Mode d'emploi • Manual de usuario
• Manual do usuário • Istruzioni d'uso • Gebruikshandleiding • Installation
A
USB
D
5
on
E
1 4
F G
5
5
Part functions:
EN
Micro USB port: Used to connect Battery charging cable. Cover during
1
washing or rinsing.
2 Battery charging cable: Used to charge keyboard battery.
Port cover: Used to cover Micro USB port during washing or cleaning.
3
4 Power switch
5 Pairing keys
6 LED indicator:
Red: keyboard battery is charging; blinking blue or green: keyboard
is trying to pair; solid blue or green: keyboard is in paired mode and
connected to computer.
USB Dongle: Used when using RF connection method to transmit
7
keyboard USB signal to computer. Located on bottom of keyboard.
RF connected Installation:
Before first installation, fully charge the battery using a 5V/1A USB
charging device and the included micro-USB cable. Place USB Dongle
(7) in computer USB port. Note that each dongle is different and is
paired with it's own keyboard. Turn keyboard on (4). Wait for keyboard
to pair automatically.
If you are using this keyboard in combination with a Man & Machine
C Mouse Wireless you can use one USB dongle to connect both
devices. Once you have installed the first device and let it pair
automatically, follow the pairing procedure to connect the second
device to the same dongle.
RF connected Pairing:
The keyboard is already paired with the USB dongle that comes with it.
7 1
5
5
6
Its Cool Flat Wireless
(Replacement drapes sold separately)
(See figure B)
(See figure A and E)
(See figure D and E)
B
6
4
7
5
BT
RF
To pair the keyboard with another dongle or to re-pair it with the dongle
it comes with: Make sure keyboard is on (4). Hold down 'ESC' and 'M'
keys simultaneously for 3 seconds to start pairing. LED indicator (6)
will blink green when pairing. Allow 20 seconds for keyboard to pair. If
the USB dongle is plugged in, unplug the USB dongle and plug it back
in. Keep the keyboard close to the USB dongle. Once the keyboard is
paired and connected to the PC, the green LED indicator will turn solid
blue (6).
Note: The keyboard will not work if it has lost it's pairing.
BT connected Installation:
Before first installation, fully charge the battery using a 5V/1A USB
charging device and the included micro-USB cable. Turn keyboard on
(4). Pair keyboard.
BT connected Pairing:
To pair or to re-pair the keyboard: Make sure keyboard in on (4). Hold
down 'BLANK' and 'F2' keys simultaneously for 3 seconds to start
pairing. LED indicator (6) will blink blue when pairing. Allow 120 seconds
for keyboard to pair. Once the keyboard is paired and connected to the
PC, the green LED indicator will turn solid blue (6).
Note: The keyboard will not work if it has lost it's pairing.
Dual use: RF and BT:
It is possible to enable RF and BT and switch between connection
methods. Follow Installation instructions for both. To switch to RF
connection, press 'BLANK' and 'F1' keys (See Figure G). To switch to BT
connection, press 'BLANK' and 'F2' keys (See Figure F).
Battery charging:
Use battery charging cable (2). Connect Micro USB connector to
keyboard, connect USB connector to 5V USB charging device or
powered USB computer port. LED indicator (6) will turn red when
charging. The red light will go off when fully charged.
Before first installation, fully charge the
battery using a 5V/1A USB charging device
and the included micro-USB cable.
1
2
5
C
(See figure E and F)
(See figure F and G)
3
3
(See figure E and F)
