GB
Maximum length of ducting run:
- 4 metres with 1 x 90° bend.
- 3 metres with 2 x 90° bends.
- 2 metres with 3 x 90° bends.
The above assumes our 150 mm (6 INS) ducting is being installed. Please note ducting components and
ducting kits are optional accessories and have to be ordered, they are not automatically supplied
with the chimney hood.
IN THE EXTRACTION MODE: Connect the hood according to Fig. 16 & 17. secure the connections with
appropriate clamping or adhesive tape
IN THE RECIRCULATION MODE: Connect the hood according to Fig. 15 with the recycling kit (Option).
To cut the rectangular tube in accordance with the position of the hole diameter 160 mm and the grid
through the plinth in the cabinet with a depth 610 mm.
8
