The Model 505 is a clamp-on multimeter that measures electrical and physical
quantities. It can perform the following functions:
AC voltage measurement

DC voltage measurement

AC current measurement

DC current measurement

Resistance measurement

Continuity test with buzzer


1.1 Interface

Clamp-On Meter Model 505

1 DESCRIPTION

Figure 1
"Delta Zero" mode

"Peak" mode

Auto Shutdown feature

"Hold" feature

Hazardous voltage warning

Item
1 Jaws
HOLD button
2
(>2 sec) PEAK button
∆ ZERO button
3
4 Rotary switch
5 LCD display screen
+ input terminal
6
COM (common) terminal
7
8 Trigger
Function
