THERMASGARD
Calibratable resistance thermometer THERMASGARD
made of impact-resistant plastic and enclosure cover with quick-locking screws, with or without optional display (for displaying actual temperature).
This room pendulum sensor is specifically designed for temperature detection in larger rooms and halls. Due to the measuring method employed by
this pendulum room temperature sensor in combination with its positioning in the room, an excellent measuring result that is representative of the
room is achieved as ambient air of the room is circulating evenly around the sensor. These temperature transmitters are factory-calibrated.
Adjustment ⁄ fine adjustment by the user is possible (zero point offset is adjustable).
Calibratable resistance thermometer THERMASGARD
made of impact-resistant plastic and enclosure cover with quick-locking screws, with or without optional display (for displaying actual temperature).
This room pendulum sensor is specifically designed for temperature detection in larger rooms and halls, as a dark radiation sensor for example. Due
to the measuring method employed by this pendulum room temperature sensor in combination with its positioning in the room, excellent and room-
representative measuring results are achieved. The globe thermometer RPTM 2 determines the effective portion of active radiation or the effective
radiant heat at the measured location. The globe temperature is determined to take heat radiation into consideration and to estimate thermal
comfortableness (operative room temperature). The operative room temperature describes the coaction of heat radiation and heat convection (the
ratio of globe temperature ⁄ air temperature is approx. 70 % ⁄ 30 %). These sensors are factory-calibrated. Adjustment ⁄ fine adjustment by the user
is possible (range and zero point are adjustable).

TECHNICAL DATA

Power supply:
Working resistance:
Load resistance:
Power consumption:
Sensor:
Measuring ranges:
Deviation, temperature:
Output:
Ambient temperature:
Connection type:
Protective tube:
Sensor protection:
Globe:
Sensor cable:
Enclosure:
Enclosure dimensions:
Cable gland:
Electrical connection:
Humidity:
Protection class:
Protection type:
Standards:
Optional:
®
THERMASGARD RPTM – Pendulum room temperature measuring transducers
Type ⁄ WG01 Sensor
RPTM 1
R P T M1- I Pt1000
R P T M1- U Pt1000
RPTM 2
R P T M 2 - I Pt1000
R P T M 2 - U Pt1000
Accessories Description
SF-M Metal sinter filter, Ø 16 mm, L = 32 mm, exchangeable, stainless steel (VA 1.4404)
Extra charge: Other ranges optional
Two-line display with illumination
2-wire connecting leads, per running meter (PVC)
RPTM
® RPTM 1 with eight switchable measuring ranges, continuous output, terminal box enclosure
®
RPTM 2 with eight switchable measuring ranges, continuous output, terminal box enclosure
24 V AC ⁄ DC (± 10 %) for U variant
15...36 V DC for I variant, depending on working resistance, residual ripple stabilised ± 0.3 V
R (ohm) = (U -14 V) ⁄ 0.02 A for I variant
a b
R > 5 kOhm for U variant
L
< 1.0 VA ⁄ 24 V DC; < 2.2 VA ⁄ 24 V AC
Pt1000, DIN EN 60751, class B
multi-range switching with 8 switchable measuring ranges, 5 measuring ranges usable,
see table (other ranges optional)
T –50 °C, T +80 °C with manual zero point correction (± 10 K)
min max
± 0.2 K at +25 °C
0 - 10 V or 4...20 mA
measuring transducer –5...+60 °C
2- or 3-wire connection
RPTM1 metal, Ø = 16 mm, L = 142 mm
RPTM1 plastic sinter filter, Ø 16 mm, L = 35 mm, exchangeable
(optional metal sinter filter, Ø 16 mm, L = 32 mm)
RPTM 2
plastic, colour black, Ø = 50 mm
PVC; LiYY, 1.5 m (other lengths optional: e. g. 3 m, 6 m)
plastic, material polyamide, 30 % glass-globe-reinforced,
with quick-locking screws, (slotted ⁄ Phillips head combination),
colour traffic white (similar to RAL 9016),
enclosure cover for display is transparent!
72 x 64 x 37.8 mm (Tyr 1 without display)
72 x 64 x 43.3 mm (Tyr 1 with display)
M 16 x 1.5, including strain relief, exchangeable,
max. inner diameter 10.4 mm
0.14 -1.5 mm², via terminal screws
< 95 % r. H., non-precipitating air
III (according to EN 60 730)
IP 65 (according to EN 60 529)
CE conformity, electromagnetic compatibility according to EN 61326,
according to EMC directive 2014 ⁄ 30 ⁄ EU
Two-line display with illumination, cutout approx. 36 x15 mm (W x H),
for displaying the ACTUAL temperature and the internal diagnostics
(measuring range exceeded, measuring range not reached, sensor breakage, sensor short circuit)
Output
4...20 mA
0 - 10 V
4...20 mA
0 - 10 V
Type
Remote sensor
Remote sensor
Remote sensor
Remote sensor
RPTM 1 = Rev. 2017 - V22 GB
RPTM 2 = Rev. 2017 - V12 GB
Item No.
with metal sleeve
1101- 1162-0219- 910
1101-11 61-0219- 910
with globe
1101-1172- 0219-910
1101-1171- 0219-910
Item No.
700 0-0050- 2200- 100
on request
