Appendix / Anhang / Appendice; A.1. Dimensions / Abmessungen / Dimensions / Dimensioni - Cedes cegard Mode D'emploi

cegard/Lift LI
A.

Appendix / Anhang / Appendice

A.1. Dimensions / Abmessungen / Dimensions / Dimensioni
Part no.: 101 072
101 073
Included in system:
100 891 and 100 892
Cross section opto edge
17
Optional: Through hole
54
Emitter
(white plug)
•
•
•
* = Attachment point Ø 4.5 mm
www.cedes.com
Installation and Operation Manual
700 ... 4000
Cable length 6 m
Optional:
70 beams

Operating range 4 ... 8 m

Customer specific solutions

with 16 or 24 elements
Receiver
(blue plug)
•
1630
1505
1380
1255
1130
1005
•
880
755
630
505
380
• 255
170
120
70
20
0
(All dimensions in mm)
