SERIES 912 - UC

1.

SAFETY INSTRUCTIONS

Make all IF, RF and supply connections before connecting the units to the
electric mains.
To meet the safety norms, the electrical installation must be protected by
a differential circuit-breaker. To connect the supply to the mains, use a
connecting strip. The green and yellow cable of the supply must be
grounded to the mains
Fig. 1 - Connection of ground cable of the power supply
Do not remove the unit covers while
connected to the mains. All repairs
must be performed by authorised
technical service
manipulation of the units cancels all
warranties.
Fig. 2 - Do not manipulate while
+ 50 °C
-- 5 °C
Fig. 3 - Range of temperatures
Serie 912 - UC
staff. Internal
connected
Make sure that the unit is properly ventilated. For
installation in a chest, use a CV-001 chest with built-in
fan (Cod. 9120068) or a CP-710 chest (Cod.
9050041) together with the VE-500 ventilator (Cod.
9050043). A unit working outside its temperature range
(-5 to +50°C) can be damaged beyond repair. Do not
block or cover the supply or cabinet ventilation slots.
230 V
GREEN/YELLOW
230 V
