11.4 FAN CONTROL MODULE REMOVAL

A. Remove inner access panel, see "INNER ACCESS PANEL"
EN
section.
B. Remove the 2 screws holding the fan control module in
unplug and remove.
C. Replace and reinstall components.
NOTE: Fan control module ON/OFF switch should
always be in the "ON" position. If for any
the module is turned "OFF", the components
plugged into the module won't have power.

11.5 NIGHT LIGHT™

Your HD81 comes equipped with 2 "Night Lights™". The lights have been pre-wired
and are controlled from the remote control.
If in the event the lamps or lens need replacing, follow the instructions below:
A. Shut off breaker at main power supply
B. Remove the four screws that secure the lens frame to the fi rebox sides.
This frame retains the glass lens.
C. The lamp can now be accessed.
NOTE: Do not handle the lamp (bulb) with bare fi ngers, protect with a
clean dry cloth.
The lamp will pull straight out of the socket. Replace
with Wolf Steel parts only, as lamp and lens are
special "high temperature" products. When
re-installing, ensure integrity of gasket seal.
THE FIREBOX MUST BE SEALED.
Over tightening the screws could break the lens.
"Light Leakage" from the holes in the housing lamp
may be observed. The holes in the lamp housing are
necessary for ventilation and must not be covered.
W415-1406 / 11.19.14
CONTROL
MODULE
CONTROL
reason
BOX
NIGHT LIGHT
place,
GASKET
LENSE
FRAME
