DIMENSIONS
B
A
Model/Modèle
A
B
4 15 / 32 (114)
Rn1
10 (254)
4 15 / 32 (114)
Rn2
10 (254)
5 7 / 8 (149)
11 1 / 2 (292)
Rn3
Dimensions in inches (mm).
Dimensions en pouces (mm)
INSTALLATION
The Rn1, Rn2, and Rn3 are designed for use with 3" and 4" schedule 40
PVC pipe, when appropriate LDVI™ coupling is used.
Prior to installation, the suction pipe should be terminated at the exterior
wall. The suction pipe should be installed with slight incline to drain water
from the fan.
DO NOT connect fan directly to building structure
Voltage
Max Amp
Rn1
120
0.17
Rn2
120
0.48
Rn3
120
1.20
C
D
C
D
1 1 / 4 (32)
9 1 / 4 (235)
1 1 / 4 (32)
9 1 / 4 (235)
1 1 / 4 (32)
9 1 / 4 (235)
Max Watts
Phase
RPM
CFM/Watts
19.7
1
3100
58.0
1
2700
141.2
1
2700
WIRING DIAGRAM
Blue
Motor
Black
Leads
Brown
There are typically three wires to be connected to an electrical fan;
Load, Neutral and Ground. Load provides power to the fan, Neutral is
for returning current and closing the electrical circuit, and Ground is
for an additional path to safely return current to the ground, in case of
an accidental electrical short in the fan and/or discharging of fan metal
components.
Fantech radon fans are permanently connected appliances employing
a reinforced polymeric construction. The non-conductive construction
functions as a "Double Insulated" protective System (Complies with
Standard for Double Insulation Systems for Use in Electrical Equipment,
UL 1097), thus eliminating the need for a grounding conductor. All
Fantech radon fans are tested and reviewed by Underwriter Laboratories,
a 3rd party independent safety governing body, and deemed suitable for
outdoor use (Standard for Safety-Electric Fans, UL 507).
Please contact Fantech Technical Support if additional information is
needed regarding this matter.
Energy Star
0.00
0.20
7.30
Yes
160
130
2.59
No
160
150
2.42
No
370
340
N (White)
L (Black)
Capacitor
CFM @ Static Pressure
0.50
1.00
1.50
2.00
80
-
-
-
120
80
40
-
280
180
120
50
3
Supply
Voltage
Max
0.89
1.97
2.36
