CAMCOLD1 – COLOUR DOME CAMERA – 6x ZOOM
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the CAMCOLD1! Please read the manual thoroughly before bringing this device into service. If
the device was damaged in transit, don't install or use it and contact your dealer.
2. Safety Instructions
Do not open the housing; risk of electroshocks.
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Keep this device away from rain and moisture.
Unplug the mains lead before opening the housing.
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• A qualified technician should install and service this device.
• Note that damage caused by user modifications to the device is not covered by the warranty.
• Keep the device away from children and unauthorised users.
3. General Guidelines
• Only use a 12VDC power supply to avoid damaging the camera.
• Do not place or mount this device on an unstable stand, tripod or bracket to prevent it form damaging.
• Do not expose the camera to direct sunlight, moisture or caustic gases.
• Do not shake the device. Avoid brute force when installing or operating the device.
• All modifications of the device are forbidden for safety reasons.
• Disconnect the device from the mains prior to maintenance activities.
• Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
• There are no user-serviceable parts.
• Contact your dealer for spare parts if necessary.
4. Connection
a. External Cable Connection
All the cameras will be connected to an RS485 adapter. A 0.5mm 8-core twisted pair will be used to connect the
dome camera and the RS485 adapter. An RJ45 crystal head is fixed on both ends of the twisted pair, which an be
inserted into the RS485 adapter and the RJ45 head of the dome camera.
