If necessary, attach two rubber stands (provided) with two (4x8 mm) screws (provided)
-
to the back of the hood.
Attach the hood-mounting bracket to the back of the hood with nine (3/16" x 3/8")
-
screws (provided) as shown in Figure 16.
Hood Installation
CAUTION: If required to move the cooking range to install the hood, turn off the power on an
electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS
RANGE.
1. Using references on Table 2 and measurements on Page 22-23, mark the leveling point
of the hood. Position two mounting screws (not provided) on the wall, leaving 1/8" away
from the wall as shown in Figure 17.
2. Align hood-mounting bracket to the two screws on the wall and hook hood into place.
Tighten screws to secure hood to the wall. CAUTION: MAKE SURE THE HOOD IS
SECURE BEFORE RELEASING.
Figure 16
13
Mounting
Screws
Figure 17
