INFOSEC UPS SYSTEM 650 XP SoHo Notice D'utilisation page 4

6 . D E S C R I P T I O N
F R O N T P A N E L
B A C K P A N E L
F U S E R E P L A C E M E N T
4
INFOSEC UPS SYSTEM - 4, rue de la Rigotière – 44700 Orvault – FRANCE - www.infosec.fr
Hot Line : tel : + 33 (0)2 40 76 15 82 - fax : + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 09 05 04 206 02
RJ11 Telephone/Fax/Internet protected outlets
3 UPS protected outlets
Input outlet
Fuse
AC input socket
Fuse
Replacement
fuse
On / Off switch
Lighting green led : AC mode
Flashing green led : Battery mode
Insert a screwdriver in the
slot to open the slide
Protection fuse
position
