Pioneer SX-S30DAB Mode D'emploi page 35

> Before Start > Part Names
Double Bass This can be selected only when "Configuration" - "Subwoofer" is
set to "Yes" and "Front" is set to "Large".
Boost bass output by feeding bass sounds from the front left and
right speakers to the subwoofer.
"On": Bass output will be boosted
"Off": Bass output will not be boosted
0 The setting will not automatically be configured even if you
performed Full Auto MCACC.
∫ Distance
Set the distance from each speaker to the listening position.
Front Left Specify the distance between each speaker and the listening
position. (Default Value is "10.0ft/3.00m")
Front Right Specify the distance between each speaker and the listening
position. (Default Value is "10.0ft/3.00m")
Subwoofer Specify the distance between each speaker and the listening
position. (Default Value is "10.0ft/3.00m")
0 Default values vary depending on the regions.
0 Distance units can be switched by pressing MODE on the remote controller. When the
unit is set as feet, you can set between 0.1 ft and 30.0 ft in increments of 0.1ft. When the
unit is set as meters, you can set between 0.03 m and 9.00 m in increments of 0.03 m.
34
> Install > Initial Setup > Playback
∫ Channel Level
Front Left Select a value between "-12 dB" and "+12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Front Right Select a value between "-12 dB" and "+12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Subwoofer Select a value between "-15 dB" and "+12 dB" (in 1 dB
increments). A test tone will be output each time you change the
value. Select the desired level (Default Value is "0 dB").
Advanced Setup | Firmware Update | Others
