Replacing the rear fan

Tips & Tricks
You need a Phillips screwdriver to add or
replace a rear fan.
Slide the hard drive bay back into position, then secure it to the case using
11
the screw you removed previously.
Replace the side panel by following the instructions in
12
panel" on page 147.
To replace the rear fan:
Remove the side panel by following the instructions in
1
panel" on page 144.
Disconnect the fan power cable from the system board.
2
Remove the four screws that secure the rear cooling fan to the case.
3
Remove the fan from the case.
4
Replacing the rear fan
"Replacing the side
"Removing the side
Screws
155
