2
1
!
When transporting always switch off all lasers, secure the pendulum
and set the slide switch to „OFF"!
2
Horizontal and vertical levelling
Release the transport restraint, set slide switch (3) to „ON". The laser cross
will appear. The laser lines can be switched with the selector button.
LASER
The transport restraint must be released for horizontal and vertical
!
levelling. The laser lines flash and a signal sounds as soon as the device
is outside the automatic levelling range of 3°. Position the device such
that it is within the levelling range.
10
EN
LASER LASER
1
Laser output windows
2 Battery compartment (backside)
3 Slide switch
a ON
5
b OFF / Transport lock /
Slope mode
a
4
1/4" tripod threads
3
(bottom)
b 5 Laser line selection button
4
LASER
