DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. Lock-off button
2. On/off switch
3. Handle
4. Battery (not included)
5. Battery unlock button
6. Pendulum action switch
7. Scale for bevel angle
8. Baseplate cover
9. Baseplate
10. Guide roller
11. Laser switch
12. Guard
13. Clamping lever
14. Wing bolts for parallel guide
15. Hex key
16. Chuck
17. Saw blade
18. Bolt for baseplate
19. Parallel guide
20. Laser
21. Cutting mark
3. ASSEMBLY
Before any work on the power tool, remove
the battery.
The battery must be charged before first use.
Inserting the battery into the machine (Fig. A, G)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (4) into the base of the machi-
ne as shown in Fig. G.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. A, G)
1. Push the battery unlock button (5)
2. Pull the battery out of the machine like shown
in Fig. G.
Replacing the saw blade (Fig. A, C)
When mounting the saw blade, wear
protective gloves. Danger of injury when
touching the saw blade.
WWW.VONROC.COM
Only use saw blades that correspond with
the characteristic data given in the
operating instructions.
Mounting the saw blade
Make sure the blade holder is free of material
debris (such as splinters of wood or metal).
1. Turn the clamping lever (13) as far to the left as
possible and hold it in this position.
2. Insert the saw blade in the chuck (16). Check
that the saw blade is securely fixed and that the
teeth are pointing in the cutting direction.
3. Let go of the clamping lever. Check whether
the back of the saw blade is positioned in the
centre of the guide roller (10).
Make sure to use the right sawblade for the corres-
ponding material. Included with the machine is a
coarse sawblade for wood and a fine sawblade for
metal and plastics.
Removing the saw blade
1. Turn the clamping lever (13) as far to the left as
possible and hold it in this position.
2. Remove the saw blade from the chuck (16).
3. Let go of the clamping lever.
Attaching the parallel guide (Fig. D)
1. Loosen the wing bolts (14).
2. Mount the parallel guide (19) onto the basepla-
te (9).
3. Set the desired cutting width using the scale
on the parallel guide (14) and the cutting mark
on the baseplate (20). The cutting mark (20)
indicates the position of the saw blade.
4. Tighten the wing bolt (14).
4. OPERATION
Switching the machine on/off (Fig. A)
The on/off switch (2) is used for activating the
machine and adjusting speed.
• To start the machine, press and hold the lock-
off button (1) and press the on/off switch (2).
• The further the on/off switch (2) is being
pushed, the faster the blade will move. The
required speeds depends on the material and
can be determined by practical testing.
• To stop the machine, release the on/off switch (2).
