4. Device description

4.1 Overview – Model number
Model number
Resolution
IP66
Operating voltage

4.2 Unpacking the device

Handle the device with extreme care when unpacking it.
First, inspect the device if the original packaging has been damaged. If the device shows
signs of damage, return it in the original packaging and inform the delivery service.

5. Installation

Instructions and installation variants for the dome cameras can be found in the quickstart installation
guide.
Please consult this guide before you proceed with the installation.

6. Quickstart guide for control units

The high-speed motorised dome can be controlled with all RS485 devices that have the Pelco D or
Pelco P protocol.
For additional information, please refer to the relevant user manual.

6.1 Control with control panel TVAC26000

The control panel TVAC26000 has been specially developed for controlling the high-speed
motorised dome TVHD75500 and therefore supports all camera functions.
For all further information on connection and operation, refer to the control panel instruction manual.
6.2 Control with recorder HDVR 3.0
You have the option to control your high-speed motorised dome with the HDVR.
The following steps are necessary for this.
1. Connect the RS-485 cables to the control interface on the HDVR.
2. Incorporate the analogue camera in the software. For more details, see the relevant user
manual.
3. Activate the pan/tilt control.
4. As the protocol type, choose ABUS Security-Center TVCC8x000.
5. Enter the ID of your camera.
TVHD75500
1080p

24 V AC
