BRKT
EXPLODED DIAGRAM
6 × 20 mm
7 Nm (0.7 m
6
572
Step
Procedure/Part name
6
Bolt
7
PTT motor
8
O-ring
PTT MOTOR, PUMP HOUSING, AND TILT
CYLINDER
kg, 5.1 ft
Ib)
•
•
6 × 75 mm
9 Nm (0.9 m
3
7
4
8
5
2
1
12 Nm (1.2 m
kg, 6.5 ft
Ib)
•
•
Q'ty
4
1
1
Reverse the removal steps for installation.
7-21
kg, 8.7 ft
Ib)
•
•
Service points
E
