Connections

Speakers/AC power supply cord
• Use only the supplied speaker cables/AC power supply cord.
• Do not connect the AC power supply cord until all other connections are
complete.
• Insert the plugs of the cables to be connected all the way in.
• Do not bend cables at sharp angles.

Speaker connection

1 Put the speakers onto
a work table with the
clean and soft cloth
(blanket, etc.).
16
(16)
Insert the speaker cables fully.
Speaker cable (supplied)
2 Insert the speaker
cables into the speaker
input terminals.
3 Insert the speaker
cables into the speaker
output terminals of this
unit.
Set the speaker cables without
snagging them.
