01 [ ]: Standby/on switch
• Press to switch the unit from on to
standby mode or vice versa. In standby
mode, the unit is still consuming a small
amount of power.
02 [CD]/[USB]/[ -PAIRING]: Select the
device to be operated ( 24, 26, 27,
28, 29)
03 [>SELECT<]: Switch the input source
( 30, 31, 32, 34)
04 [MENU]: Enter menu ( 24, 26, 28, 32,
36)
05 [SETUP]: Enter setup menu ( 38)
06 [+VOL-]: Adjust the volume
• 0 (min) to 100 (max)
07 [MUTE]: Mute the sound
• Press [MUTE] again to cancel. "MUTE"
is also cancelled when you adjust the
volume or when you turn the unit to
standby.
08 Basic playback control buttons
09 [INFO]: View content information
• Press this button to display the
track, artist, and album names, file
type, sampling frequency, and other
information. (The information varies
depending on the input source.)
10 [ ], [ ], [ ], [ ]/[OK]: Selection/OK
11 [RETURN]: Return to the previous
display
12 [DIMMER]: Adjust the brightness of
the display, etc.
• When the display is turned off, it will
light up only when you operate this
unit. Before the display turns off again,
"Display Off" will be displayed for a few
seconds. (Basic control buttons on this
unit are not turned off.)
• Press repeatedly to switch the
brightness.
13 Numeric buttons, etc.
• To select a 2-digit number
Example:
16: [ 10] > [1] > [6]
• To select a 4-digit number
Example:
1234: [ 10] > [ 10] > [ 10] > [1] > [2] >
[3] > [4]
• [CLEAR]: Clear the entered value.

Remote control code

When other equipment responds to the
supplied remote control, change the remote
control code.
• The factory default is "Mode 1".
1 Press [SETUP].
2 Press [ ], [ ] to select "Remote
Control" and then press [OK].
• The current remote control code of this
unit is displayed.
3 When "Set Mode 1/2" is displayed,
set the remote control code of the
remote control.
To set "Mode 1":
Press and hold [OK] and [1] for at least
4 seconds.
To set "Mode 2":
Press and hold [OK] and [2] for at least
4 seconds.
4 Point the remote control at this
unit, and press and hold [OK] for
at least 4 seconds.
• When the remote control code is
changed, the new code will appear on
the display for a few seconds.
■
When "Remote 1" or "Remote 2" is
displayed
When "Remote 1" or "Remote 2" is
displayed, the remote control codes of
this unit and remote control are different.
Perform step 3 above.
Control reference guide
