Mounting instruction
Back fixture when using Panda Futura sz.3+4 on Multi Frame in vehicle
Follow the description below to mount the back fixture:
1. Dismount the plastic plugs located on the Multi Frame (A)
2. Dismount the headrest fitting (B)
3. Fasten the back fixture in the Multi Frame slide (C). Mount the upper
part of the back fixture on the back of the seat, together with fitting
(B) the enclosed 4 screws and 4 washers (D).
Use the bolts (E) to adjust the height and tighten afterwards!
4. Make sure to tighten all of the screws after the correct position is
achieved.
B
E
A
A
C
D
