System resolution of the
encoder
Spindle pitch
Gear ratio
Max. speed
Max. permitted speed
Max. acceleration
Electrical specifications
Rated motor voltage
Motor output
EMC specifications
Vibration (severity 1)
Shock (severity 1)
Protection class
Permitted temperature range 0 ... +40 °C
Materials
Weight (approx.) [kg]
stroke = 50 mm
stroke = 80 mm
stroke = 100 mm
stroke = 150 mm
*)
Max. permitted speed and work load depend on each other (see chapter Characteristic
curves").
**)
The SLTE−... in conjunction with controller SFC−DC−... is intended for use in industrial
applications.
Fig. 19
36
10−...
512 pulses per revolution
5 mm
n = 57:13
*)
170 mm/s
2 mm/s
2.5 m/s
To be used only in conjunction with controller SFC−DC−...
24 V DC
4.5 W
Interference emission as per EN 61000−6−4 (industry)
Immunity to interference as per EN 61000−6−2 (industry)
0.15 mm path at 10 ... 58 Hz /
2 g acceleration at 58 ... 150 Hz
15 g acceleration at 11 ms duration
IP40
Housing, slide, driver, drive rod:
Guide, spindle:
Bearing:
0.57
0.74
16−...
1000 pulses per revolution
7.5 mm
210 mm/s
2
18 W
1.19
1.47
1.71
2.20
**)
Al
St
PA, PE
