5. CHARGING THE INTERNAL BATTERY OF THE JUMP STARTER

IMPORTANT!
CHARGE IMMEDIATELY AFTER
PURCHASE, AFTER EACH USE AND
EVERY 30 DAYS, TO KEEP THE UNIT'S
INTERNAL BATTERY FULLY CHARGED
AND PROLONG BATTERY LIFE.
To check the internal battery's charge
status, make sure the rotary switch is in the
OFF position, then press the display button
on the front of the jump starter. The digital
display will show the battery's percent of
charge. A fully charged battery will read
100%. Charge the internal battery if the
display shows it is under 100%. Complete
charging may take up to 24 hours.
5.1 Grounding and AC Power Cord
Connections
IMPORTANT: Only use the charger that
was included with the jump starter to charge
the internal battery of the jump starter.
Using a different charger could result in
personal injury or property damage.
WARNING!
RISK OF ELECTRIC SHOCK OR FIRE.
This battery charger is for use on a
nominal 120V circuit. The plug must be
plugged into an outlet that is properly
installed in accordance with all local
codes and ordinances. The plug pins
must fit the receptacle (outlet). Do not use
with an ungrounded system.
DANGER. Never alter the AC cord or plug
provided – if it does not fit the outlet, have
a proper outlet installed by a qualified
electrician. An improper connection can
result in a risk of an electric shock or
electrocution.
An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in a risk of fire and electric shock. If an
extension cord must be used, make sure:
• That the pins on the plug of the extension
cord are the same number, size and
shape as those of the plug on the charger.
• That the extension cord is properly wired
and in good electrical condition.
• That the wire size is large enough for the
AC ampere rating of the charger,
as specified:
Length of cord (feet)
AWG* size of cord
*AWG-American Wire Gauge
25 50 100 150
18 18 18 16
5.2 Charging the Jump Starter
with included Charger
1. Make sure the charger and jump starter
are placed on a dry, nonflammable
surface. To charge the jump starter, plug
the charger into the charging port on the
front of the jump starter.
2. Confirm the AC outlet voltage matches
the input voltage of the charger.
3. Connect the charger to the AC wall
outlet and confirm that the green
POWER LED on the charger turns on.
4. Check that the green
STATUS LED on the charger is pulsing
slowly, to indicate that charge process
has started. To see the status of the
charge, check the percentage shown
on the jump starter display.
5. When the jump starter display shows
100 (%), the internal battery is fully
charged and the jump starter is ready
to use. Complete charging may take up
to 24 hours.
NOTE: The green
STATUS LED will remain pulsing after
the display shows 100%, as the charger
automatically goes into Maintain mode
and maintains the battery at full charge
without damaging it.
6. After the charge is complete, disconnect
the charger from the AC outlet, then
disconnect the charger from jump starter.
5.3 Charger Modes
Automatic charging mode
When an automatic charge is performed,
the charger switches to maintain mode
automatically after the battery is charged.
Aborted Charge
If charging cannot be completed normally,
charging will abort. When charging aborts,
the charger's output is shut off. The BAD
BATTERY
not continue attempting to charge the
battery. Check the battery and replace, if
necessary.
Desulfation Mode
Desulfation could take 8 to 10 hours. If
desulfation fails, charging will abort. The
red BAD BATTERY
the yellow/orange CHARGING STATUS
LED will flash.
Completion of Charge
When the internal battery is fully charged,
the jump starter's display will show "100".
• 8 •
CHARGING
CHARGING
(red) LED will light. Do
LED will light and
