circuit breaker of the jump starter
will trip and disconnect the power to
the device. Disconnect the 12V DC
device. The breaker will automatically
reset a short time after an overload is
disconnected.
6. Recharge immediately after unplugging
the 12V DC device.
NOTE: The DC power outlet is wired
directly to the internal battery. Extended
operation of a 12V DC device may result
in excessive battery drain.
12V DC ESTIMATED RUN-TIMES
APPLIANCE
TYPE WATTAGE
Cell phone,
fluorescent light
Radio, fan,
depth finder
Camcorder

7. MAINTENANCE INSTRUCTIONS

7.1 After use and before performing
maintenance, unplug and disconnect
the jump starter.
7.2 Use a dry cloth to wipe all battery corrosion
and other dirt or oil from the battery clips,
cords and the jump starter case.

8. MOVING AND STORAGE INSTRUCTIONS

8.1 Store inside, in a cool, dry place.
8.2 Do not store the clips on the handle,
clipped together, on or around metal, or
clipped to cables. The clips on the jump
starter are live when the switch is in the
ON position and will produce arcing or
sparking if they come in contact with each
other. To prevent accidental arcing, always
place the switch in the OFF position and
keep the clips on the storage holders when
not using it to jump start a vehicle.
8.3 If the jump starter is moved around the
shop or transported to another location,
take care to avoid/prevent damage to the
cords, clips and jump starter. Failure to
do so could result in personal injury or
property damage.
IMPORTANT: Do not use and/or store the
jump starter in or on any area or surface
where damage could occur if the internal
battery should unexpectedly leak acid.
EST.
EST.
RUN TIME RUN TIME
DSR114 DSR114
4 watts 66 hrs. 132 hrs.
9 watts 29.3 hrs. 58.6 hrs.
15 watts 17.6 hrs. 35.2 hrs.
Electric tool
Electric cooler
Car vacuum,
air compressor
NOTE: Estimated run-times. Actual time may vary.
Times are based on the internal battery being fully charged.
6.3 USING THE USB PORT
The USB port provides up to 2.1A at 5V DC.
1. Ensure the battery clips are securely
2. Press the USB button on the front of
3. Plug the device into the USB port on
EST.
4. Turn the USB device on.
5. Reverse these steps when finished
6. Charge the jump starter as soon as
7.3 Ensure that all of the jump starter
components are in place and in good
working condition.
7.4 All servicing should be performed by
qualified service personnel.
8.4 IMPORTANT:
• CHARGE IMMEDIATELY AFTER
PURCHASE
• KEEP FULLY CHARGED
Charge the jump starter's internal battery
immediately after purchase, after every
use and every 30 days.
All batteries are affected by temperature.
The ideal storage temperature is at
70°F. The internal battery will gradually
self-discharge (lose power) over time,
especially in warm environments. Leaving
the battery in a discharged state may
result in permanent battery damage. To
ensure satisfactory performance and
avoid permanent damage, charge the
internal battery every month.
• 10 •
24 watts
48 watts
80 watts
clipped on the storage holders.
the unit.
the front of the unit.
using the USB port.
possible after using the USB port.
11 hrs. 22 hrs.
5.5 hrs. 11 hrs.
3.3 hrs. 6.6 hrs.
