HOW TO PERFORM A CABLE TEST
Press the red power
• Connect a network cable to the CableMaster 800/850 then connect a Network/Telephone
testing remote to the opposite end of the cable. From the home screen, press the enter
button or cable test soft key
800/850 will automatically perform a test upon entering the cable test menu.
• To test coax cable, connect a coax cable to the CableMaster 800/850, then press the coax soft
key
.
• To test telephone cable, connect the CableMaster 800/850 to a telephone cable using RJ12
patch cable, press the coax soft key
• If a remote is NOT being used (one ended test), the CableMaster 800/850 will test the
length of each pair, opens, shorts, or split pairs. Performing a one ended test will not verify
connectivity on the opposite end of the cable.
• To calibrate the VoP, connect a known length of cable to the CableMaster 800/850 and press
the up/down/left/right buttons to increase or decrease the VoP. Press the left and right
buttons to select and change the VoP one digit at a time.
• While adjusting the VoP, press the test button until the desired length of the cable is
displayed.
• To save the calibrated VoP, go to the Setup
your adjusted VoP will be displayed next to the RJ45 or Coax icon). See page 3 for Setup
instructions.
• Press the green test button tests
tests
• To save a cable test, press the save soft key
• Use the arrow buttons and the enter button to name the cable test file.
• Press the Save soft key again to save the test file
HOW TO PERFORM A PORT DISCOVERY TEST
6
T3 Innovation
NETWORK/POE TEST
• Connect the CableMaster 800/850 to a switch or active network jack.
• From the home screen, use the right arrow button to select the Network/PoE icon and press
the enter button or press the Network/PoE soft key
• The CableMaster 800/850 will automatically detect and display link capability, connection
speed, PoE mode, and PoE Min/Max voltages.
• To perform a Network Test only, press the PoE off soft key
• To save the PoE data, press the Save soft key
• Use the arrow buttons and the enter button to name the PoE file.
• Press the Save soft key to save the PoE file
button to turn the CableMaster 800/850 on
.
3
3
to display the cable test menu. The CableMaster
then the
telephone soft key.
and press the Save
or the loop mode soft key
.
.
.
.
.
soft key (note:
to perform additional
.
3
3
3
