Scope of delivery

EduKit PA Basic
The following components are included in the scope of delivery. The data sheets are arranged in numeric
order.
Data sheets Designation
162844 Pressure gauge
17070x Pipe, 4 Pcs. length 500 mm
17070x Push-in L-connector
17070x Push-in T-connector
17070x Manual valve
17070x Plug
17070x 90° push-in bracket
170712 Pump
– Switching relay
689200 Tank, round
691225 Flow sensor, variable area principle (rotameter)
— Rubber buffers
— Electrical actuation components
— Type 5 slot nuts, M4, with stud
— Connecting plate
— Profile (20 x 40 x 180 mm)
— Profile plate (20 x 200 x 350 mm)
— Brief description
Small parts included with EduKit PA Basic
Designation
Tubing D: MPS-PA-B-SCHL.15/1100
Length of pipe: MP-VT-P-15MM X 450 mm
Pipe clamps for PCS system: type 5 profile
Cable socket with socket head screw M 5x8 and type 5 slot nut
Socket head screw with internal hex: DIN 912 M 5x10 8.8, galvanised with washer and type 5 slot nut
Socket head screw with internal hex: DIN 912 M 5x16 8.8, galvanised with washer and type 5 slot nut
38
Order no. Quantity
162844 1
304518 2 m
170701 2
170702 4
170703 4
170705 1
690590 4
170712 1
– 1
689200 2
691225 1
389603 4
BG.EL.0190 1
BE.ME.0582 4
BG.ME.0179 2
660579 1
532379 1
746310 1
Quantity
1
4
2
10
2
2
