INNOMARK alpha Notice D'utilisation page 19

EN – Operating Manual
BATTERY NOTICES
The device associated with this operating manual contains
2 AA Alkaline batteries (1.5 V) in delivery condition.
These batteries are not made for recharging. The use of
a rechargeable battery is not possible with this device
and can damage it. If the included batteries are depleted,
they must not be thrown into the household waste. Used
batteries may contain harmful substances that can cause
environmental or health damage. Please return all depleted
batteries to electrical appliance stores, who collect them
for free.
BATTERY EXCHANGE
To replace the batteries, push the battery cover on the rear
of the unit downwards and replace the discharged batteries
with a new one. Be aware of the polarity when inserting the
batteries (+/- pole). Close the battery compartment cover
again. In the EU the return of used batteries is mandatory by
law. All depleted batteries and also rechargeable batteries
will be recycled. This way valuable resources like iron, zinc
and nickel can be retrieved and are reusable then. Battery
recycling is the easiest lesson in environmental protection –
so please support it!
The shown garbage bins mean that batteries or recharge-
able batteries must not be thrown into the household waste.
The signs below the garbage bins are acronyms for the
chemical substances inside the battery:
Hg Cd
Hg: Battery contains Mercury
Cd: Battery contains Cadmium
Pb: Battery contains Lead
Pb
27
TECHNICAL DATA*
Fuel Cell Sensor
Sensor
Accuracy +/- 0.05‰ (per mill) with reference
to 1.00‰ at 25°C
(per mill = default setting)
OR +/- 0.005% BAC (Blood Alcohol
Concentration) with reference to 1.00%
BAC at 25°C
OR +/- 0.025mg/L with reference to
0.50mg/L at 25°C
Detection 0.00 up to 4.00‰ (per mill)
Range OR 0.00 up to 0.40% BAC (USA)
OR 0.00 up to 2.00mg/L (UK)
Warm-up Within 10 up to 15 seconds at 0.5‰, it
Time may vary depending on the value of per
mill / BAC / mg/L which was measured
Dimension 114 x 49 x 18mm (L x W x H)
Weight 116g (batteries included)
Power 2 pieces of 1.5V AA Alkaline battery
Supply (= energy for up to max. 1,000 tests)
10°C up to 40°C
Working
Temperature
Storage 10°C up to 40°C
Temperature
Calibration Recommendation: Every 12 months
or after 300 tests (whatever comes first).
For a calibration service you can send
the device to ACE Instruments
(see www.alkomat.net).
* The technical data are subject to change without prior
notice for functional improvements.
