EN – Operating Manual
AUTHOR'S LIABILITY
All information herein was created conscientiously and
under the assumption of correctness. Hence, the author
cannot be held liable for the use of any kind whatsoever
and/or any ensuing consequences. Furthermore, the author
is not liable for any costs or expenses for damage that result
from any information in this document. Any information is
subject to change without prior notice.
INTRODUCTION
Thank you for purchasing our INNOMARK alpha
Breathalyzer! It measures the alcohol concentration in
human breath using an electrochemical sensor and
calculates the blood alcohol level. The test results are very
reliable and have a tolerance of +/- 0.05‰ (per mill = g/L)
with reference to 1.00‰ at 25°C ambient temperature. The
measurement results are displayed as a 3-digit number
with 2 decimals and are interpretable 1: 1 (for example the
display shows the value 0.36 = 0.36 per mill).
The sensor inside the device can be calibrated. To maintain
the measurement accuracy of this device and the sensor
warranty, it should be calibrated regularly. For a calibration
service you can send the device to the service address
specified at www.alkomat.net.
The device must only be used pursuant to the instructions
mentioned in this manual. All measured values determined
by this breathalyzer are always a guide only and are not
legally binding. Breath tests should be carried out using clip-
on mouthpieces (one new mouthpiece should be used per
test for reasons of hygiene and to avoid falsified readings).
NOTE TO COUNTRY-SPECIFIC MEASUREMENT UNITS
Customers in the EU receive the breathalyzer with ‰ (per
mill) as default setting, in the UK the default setting is mg/L,
and in the USA, it is % BAC. In the chapter „Technical data,"
you will find information about the accuracy concerning the
different measurement units. Please check the website of
the Department of Transportation, the website of the Ministry
of Transport, or automotive clubs to become informed about
the current alcohol limits in your country.
19
SCOPE OF DELIVERY
• 1 Digital INNOMARK alpha Breathalyzer
with fuel cell sensor
• 5 Mouthpieces
• 1 Quick Start Guide
• 1 Manual
Note: Two (2) AA alkaline batteries are required to use the
instrument and are not included.
LABEL OF INDIVIDUAL COMPONENTS
1
3
4
5
1. Mouthpiece Slot
2. Air Outlet (always keep this part unblocked)
3. Digital LC Display
4. Left Operating Button (to start a manual test,
to navigate through test results)
5. Power Button (ON/OFF, recall cumulative test count,
show last test result)
6. Right Operating Button (navigate through test results)
7. Battery Compartment Cover (on the back of the device)
2
6
7
