adey MagnaClean Atom Manuel D'installation

Masquer les pouces Voir aussi pour MagnaClean Atom:

Publicité

Liens rapides

Télécharger ce manuel
Installation and Servicing
1

Publicité

loading

Manuels Connexes pour adey MagnaClean Atom

Sommaire des Matières pour adey MagnaClean Atom

  • Page 1 Installation and Servicing...

  • Page 2: Important

    Présentation du produit – Avec sa conception compacte, le filtre MagnaClean Atom™ permet d’économiser de la place . Cela le rend idéal pour les espaces restreints mais également pour les propriétaires qui recherchent IMPORTANT une solution discrète.

  • Page 3: Installation Overview

    Mode d’installation – le filtre MagnaClean Atom peut-être installé sur le circuit de chauffage . Afin de garantir une protection efficace et continue de la chaudière , il est recommandé de monter le filtre entre le dernier radiateur et la chaudière.
  • Page 4 Open vented system / Circuit ouvert / Offenes System / Åpent ventilert anlegg / Nyitott rendszer / Układ otwarty Bottom of canister / Bas du filtre / Boden des Filterbehälters / Bunnen av filterboks / Tartály alja / Dno filtra Combi/sealed system / Circuit fermé/chaudière mixte / Kombi/ geschlossenes System /Kombinert / lukket anlegg / Kombinált/zárt rendszer /Układ zamknięty...
  • Page 5 Installation 22mm Compression 115mm 22mm Compression 22mm Compression...

  • Page 6: Bypass Mode

    Installation 3/4" BSP Remove 121mm ¾" Remove Attach Press Bypass mode Filter mode Rapide Rapide Central Heating System Central Heating System PROTECTOR PROTECTOR • Protects against corrosion and scale • Protects against corrosion and scale • Maintains heating efficiency • Maintains heating efficiency •...

  • Page 7: Filter Mode

    Installation Filter mode Replace Rapide Central Heating System PROTECTOR • Protects against corrosion and scale • Maintains heating efficiency • Faster dosing – Just 20 seconds • Helps reduce heating and maintenance bills • For use in accordance with BS7593:2006 Vent Now Register your warranty on...
  • Page 8 Servicing Annual servicing is recommended. Close Vent Bypass mode Rapide ntral Heating System ROTECTOR ects against corrosion and scale ntains heating efficiency er dosing – Just 20 seconds s reduce heating and maintenance bills use in accordance with BS7593:2006 Vent Loosen do not remove Remove...
  • Page 9 Servicing Rinse Replace sheath on magnet.
  • Page 10 Servicing Air vent Clean seals Drain valve Engage in groove Bottom Remove Tighten Tighten...
  • Page 11 Servicing 4 13 4 14 Remove Attach Press Bypass mode Filter mode Rapide Rapide Central Heating System Central Heating System PROTECTOR PROTECTOR • Protects against corrosion and scale • Protects against corrosion and scale • Maintains heating efficiency • Maintains heating efficiency •...
  • Page 12 Vent Your system is protected by Annual service required adey.com Flow resistance graph MagnaClean Atom™ pressure drop Flow [l/min]...
  • Page 13 Application MagnaClean Atom’s in-line design and 360˚ rotational valves provide multiple installation options enabling greater flexibility within the tightest working environments. For optimal results, it’s recommended that dirty systems should have a system cleanse carried out before installation of a MagnaClean ® filter. Always re-dose the system with ADEY MC1+ Rapide™...
  • Page 14 Best Practice Désembouage MagnaCleanse MagnaClean Protection Analyse d´eau Maintenance Reinigen MagnaCleanse MagnaClean Schützen Testen Wartung Rens MagnaCleanse MagnaClean Beskyttelse Test Vedlikehold Tisztítás MagnaCleanse MagnaClean Védelem Vizsgálat Karbantartás Czyszczenie MagnaCleanse MagnaClean Ochrona Badania Serwis...
  • Page 15 CAUTION: ATTENTION: ACHTUNG: CORSIKTIGHETSREGLER: FIGYELEM: UWAGA: MagnaClean filter contains a strong magnet. Keep away from all electrical devices, bank cards and other magnetic devices. Le filtre MagnaClean contient un puissant aimant. Tenir le produit à l´écart de tout appareil électrique, cartes bancaires et tout autre dispositif magnétique. MagnaClean Filter enthält einen starken Magneten, halten Sie Kreditkarten und andere magnetische Speichermedien fern.
  • Page 16 For the most up-to-date version of installation and serving instructions visit www.adey.com All ADEY marks are trademarks of Adey Holdings (2008) Limited. Please visit adey.com/trademarks for a list of ADEY marks Copyright Adey Holdings (2008) Limited © 2018. All rights reserved.
