1
While supporting the fixture, connect the supply wires to the wire connectors on the fixture. Lift the
levers on the connectors. Push the supply Hot wire into the fixture Hot (black) connector and the
supply Neutral wire into the fixture Neutral (white) connector [A]. Close the levers and visually verify the
connections.
If you need to insert more than one wire into a connector:
1. Secure a jumper wire to the extra supply wiring with a wire nut or connector that complies with local
code [B].
2. Insert the loose end of the jumper wire into the connector [B].
If the outlet box has a supply Earth/PE wire, cap it off with a wire nut or connector that complies with
local code.
North America
100–120 V
Australia
240 V
All other regions
2
Push the wires up into the outlet box. Raise the fixture to the
mounting plate and twist clockwise to lock it into place.
HAIKU® HOME WWW.HAIKUHOME.COM/SERVICE
●
AC Hot AC Neutral
Black White
Black White
Brown or Red Black or Light Blue Green with Yellow
Brown Blue
1-855-MY-HAIKU
●
Earth/PE
Green or Bare
Copper
Tracer
INSTALLATION COMPLETED
