CASTILE ENCASTRÉ
#23 Door Assembly
IMPORTANT: THIS IS DATED INFORMATION
Hearth and Home Technologies does not sell directly to consumers
distributor.
model number and serial number when requesting service parts from your dealer or distributor.
ITEM
23 Door Assembly
23.1 Door Latch Assembly
23.2 Door Frame
23.3 Screw, Pan Head Philips, 10/32 x 1/4
23.4 Hinge, Female
23.5 Glass Assembly (w/gasket) 17-1/4" W x 11-5/8" H
Gasket, Tadpole
Tape, 1/2" x 1/16
Tape, Door Corner
23.6 Retainer, Rope
24 Vacuum Switch
25 Corner Post
26 Bolt, GRD 2 Tap 3/8 x 4
27 Snap Disc, 110-20
#28 Feed Assembly
28.1
28 Feed Assembly
28.1 Screw, 8-32 x 3/8 PH,TF
28.2 Feed Motor
28.3 Collar, Set, 7/8
28.4 Bearing, Feed System, Nylon
28.5 Gasket, Feed Motor
28.6 Feed Spring Assembly
28.7 Set Screw 5/16-18 x 1/4
Additional service part numbers appear on following page.
