BRINE WELL ASSEMBLY CH20795

2
7
Item No. QTY Part No.
1 1 . CH15013-1 . . . . . . . . . . . . . . . . . . . . . . Brine Well w/Slots
2 1 . . .CH15062 Safety Brine Valve
3 2 . . .CH15070 Grommet
4 1 CH16371-16 . . . . . . . . . . . . . . . . . . . . . Tubing, 3/8" x 16" Long
5 1 . . .CH15024 Cap, Brine Well 4" Dia. (Caplug STP-4)
6 1 . CH15064-1 . . . . . . . . . . . . . . . . . . . . . . Brine Float w/One Grommet
7 1 . CH15063-1 . . . . . . . . . . . . . . . . . . . . . . Air Check Assembly
8 2 . . .BR10332 Tubing Insert, Brass
Not Shown
1 . . . . . . .CH20774 . . . . . . . Overflow Fitting Assembly
1 . . . . . . .*CH15031-1 . . . Overflow Elbow
1 . . . . . . .*CH15031-2 . . . Overflow Nut
1 . . . . . . .*CH16331 . . . . . . Gasket
*Parts included with CH20774 Overflow Fitting Assembly
18 • DE11 OM26KCS, OM32KCS, OM36KCS
5
3
6
Description
(As purchased)
1
8
4
8
