XT
COAXIAL RANGE -
rigging procedures
VERSION 1.1
4

XT AND P COAXIAL RANGES

4.1

XT Coaxial Range

®
The L-ACOUSTICS ETR8-2, ETR12, and ETR15 mounting accessories are the dedicated U-brackets for wall or
ceiling-mounting the 8XT, 12XT, and 115XT HiQ enclosures, respectively.
The L-ACOUSTICS ® XTLIFTBAR rigging accessory is dedicated for flying the 12XT and 115XT HiQ enclosures.
The system approach developed by L-ACOUSTICS
advantage of the possible configurations and optimize the system. The main components of the system are:
8XT
12XT
115XT HiQ
ETR8-2
ETR12
ETR15
XTLIFTBAR
SB118
LA4
LA RAK
LA NETWORK MANAGER
SOUNDVISION
8XT
ETR8-2
XTP_RM_ML_1.1
P
SELF-POWERED COAXIAL RANGE
® for the XT range consists of the elements needed to fully take
Passive compact coaxial enclosure
Active/passive multipurpose coaxial enclosure
Active coaxial stage monitor
Mounting accessory for the 8XT enclosure
Mounting accessory for the 12XT enclosure
Mounting accessory for the 115XT HiQ enclosure
Rigging accessory for the 12XT and 115XT HiQ enclosures
Subwoofer enclosure
Medium power amplified controller
Amp rack containing three LA8 high power amplified controllers
Software for remote controlling the amplified controllers
Acoustical and mechanical modeling software
12XT
ETR12
Figure 1: XT range components (part 1)
w w w . l - a c o u s t i c s . c o m
XTLIFTBAR
SB118
115XT HIQ
ETR15
6 en
