• Carpeting, upholstery or curtains will not reflect the laser optimally.
Measure to flat surfaces.
• Measurements made through glass (window panes) can falsify
measurement results.
• An energy-saving function switches the device off automatically.
• Clean with a soft cloth. Water may not be allowed to penetrate the
housing.

Error codes:

Err15: Outside the measuring range
Err16: Received signal too weak
Err26: Value outside display range
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing for
longer periods. Store the device in a clean and dry place.
Calibration
The meter needs to be calibrated and tested on a regular basis to ensure
it produces accurate measurement results. We recommend carrying out
calibration once a year.
Technical Data
Inside measurement range
Precision (typical)*
Laser class
Laser wavelength
Power supply
Dimensions (W x H x D)
Weight (incl. batteries)
Automatic switch-off
Operating conditions
Storage conditions
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for weakly reflective target surfaces.
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=lrmi2
LaserRange-Master i2
(Subject to technical changes without notice. 09.17)
0,3 m - 20 m
± 0,2 mm / m
2 < 1 mW
650 nm
2 x AAA 1.5 Volt batteries
40 x 110 x 24 mm
90 g
30 sec laser / 3 min device
-10°C ... 40°C, Max. humidity 20 ...
85% rH, no condensation, Max. working
altitude 2000 m above sea level
-20°C ... 70°C, Max. humidity 80% rH
